Indoor Single & Dual Color Led Display Screen
share
Detail
| Module Parameter | Pixel Pitch | 7.62mm - indoor dual color led display module type - 488×244mm | 7.62mm - indoor single red color led display module type - 488×244mm | 7.62mm - indoor dual color led display module type - 488×122mm | 7.62mm - indoor single red color led display module type - 488×122mm | 4.75mm - indoor dual color led display module type - 304×152mm | 4.75mm - indoor single red color led display module type - 304×152mm | 4.75mm - indoor dual color led display module type - 304×76mm | 4.75mm - indoor single red color led display module type - 304×76mm |
| LED Configuration & type | SMD 3IN1 3528 | SMD 3IN1 3528 | SMD 3IN1 3528 | SMD 3IN1 3528 | SMD 3IN1 2121 | SMD 3IN1 2121 | SMD 3IN1 2121 | SMD 3IN1 2121 | |
| Module Resolution | 64 X 32 Pixels | 64 X 32 Pixels | 64 X 16 Pixels | 64 X 16 Pixels | 64 X 32 Pixels | 64 X 32 Pixels | 64 X 16 Pixels | 64 X 16 Pixels | |
| Module size | 488×244mm | 488×244mm | 488×122mm | 488×122mm | 304×152mm | 304×152mm | 304×76mm | 304×76mm | |
| Physical Density | 17222 Pixels /m² | 17222 Pixels /m² | 17222 Pixels /m² | 17222 Pixels /m² | 44321 Pixels /m² | 44321 Pixels /m² | 44321 Pixels /m² | 44321 Pixels /m² | |
| Drive mode | 1/16 constant current | 1/16 constant current | 1/16 constant current | 1/16 constant current | 1/16 constant current | 1/16 constant current | 1/16 constant current | 1/16 constant current | |
| Module Net Weight | 700g | 700g | 400g | 400g | 300g | 300g | 200g | 200g | |
| Maximum Power Consumption | 18W | 12W | 8W | 6W | 14W | 12W | 7W | 6W | |
| Average Power Consumption | 8W | 5W | 4W | 3W | 5W | 4W | 3W | 2W | |
| Operating Power Source | DC 5V | DC 5V | DC 5V | DC 5V | DC 5V | DC 5V | DC 5V | DC 5V | |
| interface | HUB08 | HUB08 | HUB08 | HUB08 | HUB08 | HUB08 | HUB08 | HUB08 | |
| Protection Rating | IP31(Front Side), IP31(Back Side) | IP31(Front Side), IP31(Back Side) | IP31(Front Side), IP31(Back Side) | IP31(Front Side), IP31(Back Side) | IP31(Front Side), IP31(Back Side) | IP31(Front Side), IP31(Back Side) | IP31(Front Side), IP31(Back Side) | IP31(Front Side), IP31(Back Side) | |
| Display Optical | Brightness | ≥580cd/m2 | ≥200cd/m2 | ≥580cd/m2 | ≥200cd/m2 | ≥720cd/m2 | ≥220cd/m2 | ≥720cd/m2 | ≥220cd/m2 |
| View Angle | 100°(h) 100°(v) | 100°(h) 100°(v) | 100°(h) 100°(v) | 100°(h) 100°(v) | 100°(h) 100°(v) | 100°(h) 100°(v) | 100°(h) 100°(v) | 100°(h) 100°(v) | |
| Minimum View Distance | 7m | 7m | 7m | 7m | 4m | 4m | 4m | 4m | |
| Display Power | Maximum Power Consumption | 150 W/m2 | 100 W/m2 | 140 W/m2 | 100 W/m2 | 350 W/m2 | 300 W/m2 | 350 W/m2 | 300 W/m2 |
| Average Power Consumption | 60 W/m2 | 40 W/m2 | 60 W/m2 | 40 W/m2 | 150 W/m2 | 100 W/m2 | 150 W/m2 | 100 W/m2 |
