Detail
| Pixel Pitch | LED type SMD | module size（mm） | interface | IC qty | module resolution | module total pixel | common type | each powel supply can support module qty at most （*0.75） | power consumption | |||
| brightness （cd/m²） | module current（A） | 5V/40A*0.75 | 5V/60A*0.75 | average （w/㎡) | maximum. （w/㎡) | |||||||
| P1.86-43S | 1515 | 320*160 | HUB75E | 66 | 172*86 | 14792 | 500-600 | 3.5-4.5 | 8 | 10 | 240 | 650 |
| P2-32S | 1515 | 256*128 | HUB75E | 48 | 128*64 | 8192 | 500-600 | 3.0-4.0 | 8 | 11 | 240 | 650 |
| P2-40S | 1515 | 320*160 | HUB75E | 60 | 160*80 | 12800 | 500-600 | 3.5-4.5 | 8 | 10 | 240 | 650 |
| P2-30S | 1515 | 240*120 | HUB75E | 48 | 120*60 | 7200 | 500-600 | 3.0-3.5 | 8 | 12 | 220 | 600 |
| P2.5-24S | 2121 | 240*120 | HUB75E | 36 | 96*48 | 4608 | 500-600 | 2.5-3.5 | 8 | 12 | 220 | 600 |
| P2.5-32S | 2121 | 320*160 | HUB75E | 48 | 128*64 | 8192 | 500-600 | 3.5-4.5 | 8 | 10 | 240 | 650 |
| P3-20S | 2121 | 240*120 | HUB75 | 30 | 80*40 | 3200 | 500-600 | 2.5-3.5 | 8 | 12 | 220 | 600 |
| P3-32S | 2121 | 192*192 | HUB75E | 24 | 64*64 | 4096 | 500-600 | 2.5-3.5 | 8 | 12 | 220 | 600 |
| P4-16S | 2121 | 256*128 | HUB75 | 24 | 64*32 | 2048 | 750 | 2.5-3.5 | 8 | 12 | 220 | 600 |
| P5-16S | 2121 | 320*160 | HUB75 | 24 | 64*32 | 2048 | 500 | 3.0-4.0 | 8 | 12 | 220 | 600 |
ELECTRONIC
DISPLAY SCREEN
LIGHT DISPLAY TECHNOLOGY
VERTICAL
WALL MOUNTED
INVERSION
