Outdoor Waterproof Full Color Led Display Screen

WeChat

Sina Weibo

QQ space

Douban

Baidu Post Bar

+8613726029261

Reservation Now

Detail

Pixel Pitch	LED type SMD	module size（mm）	interface	module resolution	module pixel total	common type		each powel supply can support module qty at most （*0.75）		power consumption
						brightness （cd/m²）	module current（A）	5V/40A*0.75	5V/60A*0.75	average（㎡/w)	maximum㎡/w)
P2.5-32S	1415	320*160	HUB75	128*64	8192	4800-5000	7.5-8.5	3	5	350	900
P2.5-16S	1415	320*160	HUB75	128*64	8192	4800-5000	5.5-7.0	4	6	300	800
P2.5-16S	1415	160*160	HUB75	64*64	4096	5000-5200	4.5-5.5	5	8	280	700
P2.976-21S	1415	250*250	RV907	84*84	7056	3500-3800	5.5-7.0	4	6	300	800
P2.976-21S	1415	250*250	HUB75	84*84	7056	3500-3800	5.5-7.0	4	6	300	800
P3-16S	1415	192*192	HUB75	64*64	4096	4800-5000	4.5-5.5	5	8	280	700
P3-16S	1921	192*192	HUB75	64*64	4096	4800-5200	4.5-5.5	5	8	280	700
P3.076-13S (high brightness)	1415	320*160	HUB75	104*52	5408	5500-6000	7.5-8.5	3	5	400	900
P3.076-13S	1415	320*160	HUB75	104*52	5408	4800-5000	5.5-7.0	4	6	300	800
P3.33-15S	1921	200*200	HUB75	60*60	3600	4500-5000	4.5-5.5	5	8	280	700
P3.84-13S	1921	200*200	HUB75	52*52	2704	4500-5000	4.5-5.5	5	8	280	700
P3.91-8S	1921	250*250	HUB75	64*64	4096	5000-5500	7.5-8.5	3	5	300	800
P3.91-16S	1921	250*250	HUB75	64*64	4096	3500-3800	5.5-7.0	4	6	300	800
P4-8S	1921	256*128	HUB75	64*32	2048	5000-5800	4.5-5.5	5	8	280	700
P4-8S	1921	256*128	HUB75	64*32	2048	5000-5800	4.5-5.5	5	8	280	700
P4-10S	1921	320*160	HUB75	80*40	3200	4500-4800	5.5-7.0	4	6	300	800
P4-10S (high brightness)	1921	320*160	HUB75	80*40	3200	5500-6000	7.5-8.5	3	5	400	900
P4-10S	1921	320*320	HUB75	80*80	6400	4500-4800	14-16	2	3	400	800
P4.81-13S	1921	250*250	HUB75	52*52	2704	3500-3800	5.5-7.0	4	6	300	800
P4.81-13S	2525	250*250	HUB75	52*52	2704	3500-3800	5.5-7.0	4	6	300	800
P4.81-13S	2727	250*250	HUB75	52*52	2704	3500-3800	5.5-7.0	4	6	300	800
P4.81-7S	1921	250*250	HUB75	52*52	2704	5000-5500	7.5-8.5	3	5	300	800
P5-8S (high brightness)	1921	320*160	HUB75	64*32	2048	5500-6000	7.5-8.5	3	5	400	900
P5-8S	1921	320*160	HUB75	64*32	2048	4500-4800	5.5-7.0	4	6	300	800
P5-8S small module	2525	160*160	HUB75	32*32	1024	5500-6000	4.5-5.5	5	8	280	700
P5-8S	2727	320*160	HUB75	64*32	2048	4500-4800	5.5-7.0	4	6	300	800
P5-8S small module	2727	160*160	HUB75	32*32	1024	4500-4800	3.5-5.5	5	8	280	700
P5-8S	1921	320*320	HUB75	64*64	4096	4500-4800	14-16	2	3	300	800
P5.95-7S	2727	250*250	HUB75	42*42	1764	3500-3800	5.5-7.0	4	6	300	800
P6-4S (high brightness)	1921	192*192	HUB75	32*32	1024	5500-5800	5.5-7.5	4	6	300	800
P6-8S	2727	192*192	HUB75	32*32	1024	4500-5000	3.5-5.5	5	8	280	700
P6-4S(XG)	3535	192*192	HUB75	32*32	1024	5500-6000	5.5-7.0	4	6	300	800
P6-8S	3535	192*192	HUB75	32*32	1024	4500-5000	3.5-5.5	5	8	280	700
P6.67-6S	2727	320*320	2 HUB75	48*48	2304	4500-5000	15-16	2	3	300	800
P6.67-6S	2727	320*160	HUB75	48*24	1152	4500-5000	5.5-7.0	4	6	300	800
P6.67-4S (high brightness)	2727	320*160	HUB75	48*24	1152	5000-5800	8.5-10	3	5	350	900
P6.67-6S	3535	320*160	HUB75	48*24	1152	4500-5000	5.5-7.0	4	6	300	800
P8-5S	3535	320X160	HUB75	40*20	800	4500-4800	5.5-7.0	4	6	300	800
P8-4S	3535	256*128	HUB75	32*16	512	5000-5200	4.5-5.5	5	8	280	700
P8-5S	3535	320X160	HUB75	40*40	1600	4500-4800	13-15	2	3	300	800
P10-4S	3535	320*160	HUB75	32*16	512	3500-3800	4.5-5.5	5	8	280	700
P10-2S	3535	320*320	2 HUB75	32*32	1024	5500-6000	15-16	2	3	300	800
P10-2S	3535	320*160	HUB75	32*16	512	5500-6000	8.0-10	3	5	300	800
P12.5 static	3535	200*200	HUB75	16*16	256	5000-5500	7.5-8.5	3	5	300	800
P16 static	3535	256*256	HUB75	16*16	256	5000-5200	8.0-10	3	5	300	800
