| specification | P2.6-5.2/5.6/6.944 | P2.8-5.6 | P2.9-6.2 | P3.9-7.8 | P10.4 |
| LED type | SMD | SMD | SMD | SMD | SMD |
| pixel pitch | 2.6mm*5.2/5.6/6.944mm (x*y) | 2.8mm*5.6mm (x*y) | 2.9mm*6.2mm (x*y) | 3.9mm*7.8mm (x*y) | 10.4mm*10.4mm (x*y) |
| physical density | 73728/65824/55296 pixel/㎡ | 61952 pixel/㎡ | 53760 pixel/㎡ | 32768 pixel/㎡ | 9216 pixel/㎡ |
| Permeability | 65% | 55% | 55% | 60% | 65% |
| cabinet size | 1m*1m (w*h) | 1m*1m (w*h) | 1m*1m (w*h) | 1m*1m (w*h) | 1m*1m (w*h) |
| cabinet weight | 7kg/㎡ | 9kg/㎡ | 7kg/㎡ | 7kg/㎡ | 7kg/㎡ |
| brightness | 2000-4500CD | 1000-5000CD | 1000-2500CD | 600-6000CD | 500-5500CD |
| refresh rate | 1920-3840Hz | 1920-3840Hz | 1920-3840Hz | 1920-3840Hz | 1920-3840Hz |
| protection grade | IP30 | IP30 | IP30 | IP30 | IP30 |
| max consumption | 600-800W/㎡ | 600-800W/㎡ | 600-800W/㎡ | 300-800W/㎡ | 400-800W/㎡ |
| work temperature | -10~45℃ | -10~45℃ | -10~45℃ | -10~45℃ | -10~45℃ |
